Common Problems
Design a Payment System like Stripe
Understanding the Problem
Functional Requirements
Core Requirements
- Merchants should be able to initiate payment requests (charge a customer for a specific amount).
- Users should be able to pay for products with credit/debit cards.
- Merchants should be able to view status updates for payments (e.g., pending, success, failed).
Below the line (out of scope):
- Customers should be able to save payment methods for future use.
- Merchants should be able to issue full or partial refunds.
- Merchants should be able to view transaction history and reports.
- Support for alternative payment methods (e.g., bank transfers, digital wallets).
- Handling recurring payments (subscriptions).
- Payouts to merchants.
Non-Functional Requirements
The Set Up
Defining the Core Entities
API or System Interface
High-Level Design
1) Merchants should be able to initiate payment requests
2) Users should be able to pay for products with credit/debit cards.
3) The system should provide status updates for payments
Potential Deep Dives
1) The system should be highly secure
2) The system should maintain strong consistency for financial transactions
3) The system should be scalable to handle high transaction volume (10,000+ TPS)
Servers
Kafka
Database
4) How can we expand the design to support Webhooks?
What is Expected at Each Level?
You may be thinking, "how much of that is actually required from me in an interview?" Let's break it down.
Mid-level
For a mid-level candidate discussing a payment system, I'd primarily focus on your ability to establish the core functionality. You should be able to design a straightforward payment flow that handles the basic requirements of initiating payment requests, processing cards, and returning status updates.
You should demonstrate understanding of the need for security in payment systems and identify that sensitive card data shouldn't touch merchant servers. However, I wouldn't expect you to deeply understand all the nuances of payment security or complex tokenization approaches. When discussing consistency, a reasonable solution like assuming timeouts mean failure (even if not ideal) would be acceptable as long as you can explain the approach clearly. I'd be looking more at your problem-solving process than expecting a perfect solution to complex payment reconciliation challenges.
I'd anticipate that you might need guidance on deeper technical challenges, and that's perfectly fine. The interviewer will likely direct the conversation through the latter portions of the discussion.
Senior
For a senior engineer, I'd expect you to move quickly through the basic functionality and drive the conversation toward the critical non-functional aspects of a payment system. You should proactively identify security and consistency as core challenges.
On the security front, you should propose a solution like the iframe isolation approach and understand its benefits in protecting sensitive card data. You should be able to articulate why this approach is superior to having merchants collect card data directly. For payment consistency, you should recognize that timeouts don't necessarily mean failure and propose a more sophisticated approach like idempotent transactions with pending resolution. You should be able to identify potential race conditions and explain how your design prevents double-charging.
For scaling discussions, I'd expect you to speak with confidence about how you'd implement horizontal scaling for services and databases, though you might need some prompting to explore more advanced topics like Kafka partitioning strategies or event sourcing.
Staff+
As a staff+ candidate, I'd expect you to demonstrate deep expertise in payment systems design while also showing exceptional product and architectural thinking. Rather than rushing to complex solutions, you should first evaluate whether they're necessary. For instance, you might point out that for many payment scenarios, event sourcing with reconciliation is the right approach not just for technical reasons but because it aligns with how financial systems fundamentally work - acknowledging the inherently asynchronous nature of payment networks. For security, you should be able to explain multi-layered approaches like tokenization with client-side encryption, showing an understanding of the defense-in-depth strategy necessary for handling sensitive financial data.
You should proactively identify and address the most challenging edge cases in payment processing. For example, you might discuss how to handle payment network outages through fallback processing paths or how to design resilient reconciliation processes that guarantee eventual consistency with external payment networks.
